| Manufacturer: | Shenzhen Energy Co., Ltd | Type: | Rechargeable Battery |
|---|---|---|---|
| Operating Temperature: | -40°C To 65°C | Applications: | Forklift ,Backup Pwer,low Temperature Application |
| Voltage: | 3.1V | Capacity: | 20Ah |
| Chemistry: | Sodium Ion | Country Of Origin: | China |
| High Light: |
Rechargeable Na+ battery cell, 20Ah Na+ battery cell, Rechargeable Sodium Ion Batteries |
||
| No. | Item | Specifications |
| 1 | Model No. | YX 40160-20Ah |
| 2 | Typical Capacity | 20Ah @0.5C Discharge |
| 3 | Minimum Capacity | 19.5Ah @0.5C Discharge |
| 4 | Nominal voltage | 3.1V |
| 5 | Standard Charge | CC/CV,0.5C,3.95V |
| 6 | Standard Discharge | CC,0.5C,2V |
| 7 | Cut-off charge Voltage | 3.95V |
| 8 | Cut-off charge Current | 0.05C(At CV mode) |
| 9 | Cut-off discharge Voltage | 2V |
| 10 | Quick Charge Current | 1C |
| 11 | Max Discharge Current | 2C |
| 12 | Initial Impedance | 1.2±0.3mΩ |
| 13 | Operating temperature | Charging: -10℃~60℃ Discharging:-40℃~65℃ |
| 14 | Storage temperature | 3month:-40℃~35℃ 6month :-10℃~25℃ |
| 15 | Storage Humidity | ≤75%RH |
| 16 | Cycle life | ≥1500 cycles |
