YX-TPF50CC

1. Model: TPF50CC
2. Typical Capacity: 50Ah
3. Rated Voltage: 3.2V
4. Standard Charging: CC/CV, 1C, 3.65V
5. Standard Discharging: CC, 1C, 2.0V
6. Cut-off Discharge Voltage: 2.0V
7. Maximum Continuous Discharge Current: 200A (4C)
8. Maximum Peak Discharge Current: 6C for 30 seconds
9. Maximum Continuous Charging Current: 75A (1.5C)
10. Initial Impedance: ≤0.7mΩ
11. Operating Temperature: Charging: 15 to +35℃; Discharging: 10 to +35℃
12. Storage Temperature: -20 to +60℃
13. Storage Humidity: ≤70% RH
14. Dimensions: 27*148*134 mm
15. Weight: 1110±20 g
